Resin sand reclaiming and molding system

Introdction:
Resin sand reclaiming and molding systerm is of low energy consumption, less sand crushing, high regeneration efficiency, less wearing parts, easy maintenance, small occupied area and so on. This machine is a combination of regenerating and winnowing.And it has got the ISO9001:2008 certificatation. Number is 07611Q11033ROS.

Components of resin sand reclaiming and molding system

1.shakout machine
2.vibrating conveyor
3.lifter
4.sand bin
5.vibrating feeder
6.vibrating crusher
7.magnetic separator
8.reclaimer
9.sand boilig and cooling bed
10.sand mixer

Working principle
1.Resin on the used sand is removed by well-engineered combustion technology
2.This curshed and segregared sand is heated to burn the resin and the sand is recycled again.
3.Heat generated from resin burning can be recovered to preheat the sand as well as combustion air

Features

1.Optimized secondary fuel consumption(LPG) depending on the properties of resin
2.Low Operating Cost
3.Fully automatic plant with instrumentation for process control
4.safe and reliable operation
5.smooth and consistent operation regardless of variations in resin content
6.Tailor made capacities available
